Homematic IP floor heating actuator for up to six 230 V valve drives This actuator can control a total of six 230 V valve drives that are designed to regulate a water-based floor heating system. It makes heating a part of the Homematic IP home automation system and can be controlled via the app (via Access Point), WebUI (via CCU3) or the Homematic wall thermostat. Three of the six heating zones are equipped with double clamp terminals for the assignment of two heating circuits. - Included: Homematic IP six-channel floor heating actuator, two screws, two rawlplugs, user manual - Supply voltage: 230 V/50 Hz - Current consumption: max. 6.3 A - Max. switching capacity: 1,380 W (channel 1), 253 W (channel 2 to 6) - Cable: rigid and flexible cable, 0.12 to 0.5 mm² - Radio frequency: 868.0 - 868.6 MHz, 869.4 - 869.65 MHz - Radio range: 270 m outside - Ambient temperature: 0 °C to 50 °C - Weight: 566 g
