Complete PCB Design Using OrCAD Capture and PCB Editor, Second Edition, provides practical instruction on how to use the OrCAD design suite to design and manufacture printed circuit boards. Chapters cover how to Design a PCB using OrCAD Capture and OrCAD PCB Editor, adding PSpice simulation capabilities to a design, how to develop custom schematic parts, how to create footprints and PSpice models, and how to perform documentation, simulation and board fabrication from the same schematic design.This book is suitable for both beginners and experienced designers, providing basic principles and the program's full capabilities for optimizing designs. Companion sitehttps://www.elsevier.com/books-and-journals/book-companion/9780128176849 Format Häftad Omfång 612 sidor Språk Engelska Förlag Elsevier Science Publishing Co Inc Utgivningsdatum 2019-06-21 ISBN 9780128176849
