8 Bar MAP Sensor EU (MAP8EU) The 8 Bar MAP Sensor EU (MAP8EU) measures up to 7 Bar absolute pressure, making it suitable for turbo and supercharger applications with boost pressures up to 7 Bar (~101 PSI). Features: Connector and pins included Easy installation: Insert the wire through the connector, crimp the terminal, and pull the wire/terminal back into the connector Compatible with Link G4/G4+/G4X ECUs, select "Variohm 8 Bar" as the MAP sensor type in PC Link Calibration: 0 kPa = 0.5 V 800 kPa = 4.5 V Pinout: PIN A = 0 V PIN B = 5 V PIN C = Signal Optimal for motorsport applications requiring extremely high boost pressures up to 7 Bar.
