ECU Master PMU-24 DL PMU-24 DL is a new and enhanced Power Management Unit featuring all the benefits of the PMU-16, now with 24 high-side outputs and internal data logging memory as a standard. All output states, voltage, and current information can be transmitted via CAN bus to a dash display to inform the driver of potential problems. All logged data can be downloaded from the device for later analysis. Features: 170 Amps total continuous current.   Operating voltage: 6-22V (immunity to transients according to ISO 7637)   Temperature range: AECQ-100 GRADE 1, -40 to +125°C.   10x 25 Amps high-side power outputs (PWM capable).   6x 15 Amps high-side power outputs.   8x 7 Amps high-side power outputs.   Up to 16 analog inputs.   24x tricolor LED for each power output state.   2x CAN 2.0 A/B.   256 MB data logger memory.   Up to 500 Hz logging frequency.   Real-time clock for data stamping.   3D accelerometer/gyroscope.   Built-ininertia switchin case of an accident.   Easy access t
