Low profile lift table, U platform, max. load 1000 kg, operating voltage 400 V. Supplied = assembled. Max. load = 1000 kg. Lifting range = 80 - 840 mm. Platform design = U-shaped. Operating voltage = 400 V. Control voltage = 24 V. Platform colour = light blue RAL 5012. Frame colour = jet black RAL 9005. Fittings = with hand operated control unit. Internal width = 580 mm. Product type = low profile lift tables. Lifting capacity at full load in 1 shift operations = 6 cycles per hour. Lifting time without load = 18 sec. Lifting time with full load = 23 sec. Platform width = 1140 mm. Suitable for Euro pallets and industrial pallets. A counterbalance forklift is not required. U platform The very low profile enables pallet trucks and drawbar stackers to enter the lift table and set down a pallet. All lift tables are fitted with safety rails and safety valves, and comply with EN 1570-1 as well as VDE requirements.
