ECU Master Wheel Speed to CAN Reading and processing wheel speed data is a common issue in modern race cars. Most modern ABS systems use active magnetoresistive sensors, and attempts to "tap" into these signals can cause errors in the ABS system. To assist our customers, we have designed the ultimate solutionWheel Speed to CAN. This compact unit reads wheel speed sensors and sends the data via CAN bus to other devices such as dashboards, data loggers, and ECUs. Most importantly, the signal from the sensors is not interfered with and maintains the full functionality of the traction control system. The module can also be used as an expansion module if a direct connection of all 4 wheel speed sensors to the ECU (if there are not enough inputs) is not possible. Features: Supports up to 4 magnetoresistive / VR / Hall sensors. CAN 2.0A/B (125, 250, 500, 1000 kbps), customizable messages and data formats. Free software upgrades. Configurable via CAN BUS. WheelSpeedToCAN_manual DrawingsW
